High Frequency Geophone Element Advanced Forecasting OEM Service

Brand Name : EGL

Model Number : EG-100-II

Place of Origin : CHINA

MOQ : 1 pcs

Payment Terms : Western Union, T/T,PayPal

Supply Ability : 10000pcs/month

Delivery Time : 5-8 work days

Packaging Details : Carton

Natural Frequency ( Hz ) : 100Hz ± 10%

Sensitivity With Shunt Resistor ( v/m/s ) : 35.0 v/m/s ± 5%

Coil resistance : 820 Ω ± 10%

Moving Mass : 9.0g

Harmonic distortion ( % ) : ＜0.2%

Typical Spurious Frequency (Hz ) : ≧300Hz

Price : Negotiable

Contact Now

Geophone 100Hz , Vertical / Horizontal

The Geophone 100Hz (EG-100-II) is a conventional type of moving coil geophone with small error in working parameters and stable and reliable performance. The structure is reasonable in design, small in size and light in weight, and is suitable for seismic exploration of strata and geological environments of different depths.

Type	EG-100-II
Natural Frequency ( Hz )	100 ±10%
Coil resistance(Ω)	820 ±10%
Open Circuit Damping	0.50 ±10%
Open Circuit Intrinsic Voltage Sensitivity( v/m/s )	35.0 v/m/s ± 5%
Harmonic distortion ( % )	＜0.2%
Typical Spurious Frequency (Hz )	≧300Hz
Moving Mass ( g )	9.0g
Typical case to coil motion p-p ( mm )	1.2mm
Allowable Tilt	≦20º
Operating Temperature Range ( ℃ )	-40℃ TO +100℃
Height ( mm )	32mm
Diameter ( mm )	26mm
Weight ( g )	80g
Warranty Period	3 years

All parameters specified here in are rated at a temperature 20℃±2℃ .
